TELD / Terminals & accessories
Cable management
Single- and dual-cable management units
A constant-force spring mechanism supports the charging cable and reduces cable dragging. Available in single- and dual-cable configurations to complement compatible charging equipment.
Single cable connector · Dual cable connector
PRODUCT OVERVIEW
Designed around
the application.
- Constant-force spring support
- Four-screw installation
- Cable support above ground
Source: TELD Charging Product (IEC), V4.1, page 12. Manufacturer specifications; subject to final model and configuration confirmation.
Technical specifications
| Configurations | Single / dual cable |
|---|---|
| Stretch length | 1.5 m |
| Service life | ≥10,000 cycles (manufacturer specification) |
| Construction | Steel |
| Protection | IP54 |
| Operating temperature | −25 to +55°C |
| Operating humidity | 5–95% RH |
| Dimensions (W × D × H) | 791 × 110 × 2,056 mm |
